Physicochemical effects remain elusive in the theory of porous media. A continuum theory is presented for modeling the chemomechanical behavior of unsaturated soils with chemomechanical coupling. The new theory effectively explains many salient phenomena occurring in soils and describes the multiple coupled processes in the vadose zone.

Abstract

A theoretical framework is presented for modeling the chemomechanical behavior of multiphase porous media, in general, and unsaturated soils, in particular, which can address skeletal deformation, fluid flow, heat conduction, solute diffusion, chemical reaction, and phase transition in a consistent and systematic way. A general expression is derived for the electrochemical potential of a fluid species with explicitly accounting for the effects of osmosis, capillarity, and adsorption. The equilibrium behavior of porous media is investigated, and the composition of pore water pressure is identified. Explicit formulations are developed for the effective stress and intergranular stress, with consideration of physicochemical effects. It is shown that the negative water pressure measured by a conventional transducer can be significantly different than the true pore water pressure. It is also theoretically revealed that, other than the soil water characteristic function, a new pressure (or potential) function accounting for the physicochemical effects is generally required in analyzing the coupled chemomechanical processes in unsaturated soils. The new theory is capable of effectively explaining many salient phenomena occurring in water-saturated porous media with a degree of saturation varying from an extremely low value to 100%, including Donnan osmosis, capillary fringe, air entry value, initial hydraulic head during seepage, and pressure solution. The new theory can be used to analyze the multiple coupled physical and chemical processes in the vadose zone.

Chemomechanical behavior of porous media with multiphases and multispecies is of great interest in many diverse fields of science and engineering. To mention a few, this includes the industries of nuclear, hazardous, and municipal waste isolation; petroleum and gas extraction; technologies of methane gas hydrates exploitation; CO2 sequestration; and weak soil reinforcement, landform stability assessment, structural material durability, and weathering of rock masses. Understanding, controlling, and predicting the long-term effect of physicochemical processes on the mechanical performance of geomaterials is becoming an indispensable part of environmental impact assessment and performance assessment analysis. Thus, there is a clear need to develop comprehensive chemohydromechanical mathematical modeling capacities that are able to address realistically the reactive multispecies transport, multiphase flow, chemical reaction, phase transition, chemically induced deformation, and other related physicochemical processes in deformable soils.

The coupling of multiple processes in porous media, including skeletal deformation, seepage, diffusion, and heat conduction, has been extensively investigated, and the poromechanic theory that is capable of describing these coupled physical processes has been very well developed (e.g., Coussy, 2004). Thus far, however, the behavior of porous media with multiphase and multispecies where physicochemical effects come into play remains elusive. Earlier research and practices were mainly concerned with reactive flow and transport, and numerous flow and transport models have been developed, without addressing mechanical issues (e.g., Spycher and Sonnenthal, 2003; Steefel et al., 2005; Xu and Pruess, 2001). With regard to the chemomechanical behavior of porous media, a few research studies have been performed with a focus on the chemoplasticity of fully saturated soils (e.g., Hueckel, 2002; Loret et al., 2004; Witteveen et al., 2013). In addition, the cross-scale effect and multiprocesses coupling of multiphase systems has been an active field of research on experimental, theoretical, and numerical bases (e.g., Di Maio et al., 2002; Coussy, 2010).

Over the past two decades, numerous efforts have been devoted to developing general theoretical frameworks for modeling multiphase and multispecies porous media. Among these, we mention the biological tissues-oriented theory of porous media developed by Huyghe and his coworkers (Huyghe and Janssen, 1997; Huyghe et al., 2004, 2007) and the hybrid theory of swelling porous media (Bennethum and Cushman, 1996a,b; 2002a,b; Bennethum et al., 1996, 2000; Bennethum, 2007, 2012). Through these efforts, general macroscopic governing equations have been developed that can be used to address the physicochemical and electrochemical coupling in multiphasic and multispecies systems. In addition, the significances and implications of pressures and potentials have been well addressed.

Despite of this progress, a comprehensive theoretical framework is still lacking for modeling the chemomechanical behavior of unsaturated soils with variable saturation. Here our hypothesis is that when the saturation varies from 100% to a low extreme, the composition and concentration of a pore fluid are variable, resulting in intensive physicochemical effects in the soils. Indeed, for the unsaturated soils with low saturation, the pore water pressure (PWP) has not been very well defined, and in current practice, the methods for PWP measurement are used quite ambiguously, even without distinguishing the difference between the potential and the pressure. To overcome such difficulties, several fundamental issues have to be resolved, including:

  • How do we reconcile the concepts of potentials and stresses (or pressures) in a unique framework that is used to address the coupled thermo-hydro-chemo-mechanical processes in unsaturated soils?

  • How do we characterize the chemical potential of a species in the unsaturated soils with multispecies, where osmotic, capillary, and adsorptive effects are important?

  • What is the explicit expression of the effective stresses when compositions and concentrations of pore water are variable?

Solving the first problem depends largely on the answers to the last two issues. Based on fundamental thermodynamic principles and an averaging procedure, Nitao and Bear (1996) had rigorously derived mathematical formulations for the potentials of unsaturated soils and provided a complete set of governing equations for flow and transport processes in the soils. Although this framework describes the flow and transport processes in a multiphase system, it does not address the mechanical issues.

As one of the fundamental concepts in the classical soil mechanics, the effective stress concept plays a crucial role in describing the mechanical behavior of saturated soils. After Terzaghi’s proposal for it, intensive efforts have been made to extending the effective stress concept to unsaturated soil problems (e.g., Bishop, 1959; Kohgo et al., 1993; Khalili et al., 2004; Laloui and Nuth, 2009). Perhaps the most commonly used formulation of the effective stress for unsaturated soils is the one proposed by Bishop (1959). This equation states that the effective stress of unsaturated soils is equal to the total stress minus the averaged pore pressure that is the average of pore air and pore water pressure weighted by factor χ. The validity of Bishop effective equation have been recently examined by Gray and Miller (2007), Gray and Schrefler (2007), Gray et al. (2009), and Nikooee et al. (2012), based on the principles of thermodynamics and a local averaging procedure with explicit consideration of interfacial effects. These authors have shown that Bishop’s effective stress can be theoretically recovered only if the interfacial tension terms are neglected.

In a somewhat intuitive way, Lu and Likos (2006) and Lu et al (2010) have proposed a new formulation for the effective stress of unsaturated soils, which includes a stress term called the “suction stress.” Remarkably, the suction stress accounts for the effect of surface tension, negative pore pressure, electrochemical interactions, and other factors related to unsaturated soils. The applicability of the suction stress concept has been validated based on the shear strength properties of unsaturated soils extensively collected from the literature. Thus far, however, a solid theoretical basis has yet to be built for this concept.

On the basis of the approach of the mixture hybrid theory, a detailed derivation of a comprehensive theoretical framework is presented here that can be used to describe the chemomechanical behavior of unsaturated soils with saturation varying from 100% to a low extreme value. Within this context, the effective stress concept is examined, and the general expression for the chemical potential of a species is developed. To shed new insights into the unsaturated soil behavior, equilibrium behavior of the soils is investigated in detail.

Thermodynamic Constraints

Preliminary

The unsaturated soils under consideration are viewed as the porous continua composed of a solid matrix (s) with interconnected pores saturated with two immiscible fluids, namely, a liquid (l) and a mixed gas (g). Unless otherwise specified, symbol α or β represents a bulk phase, i.e., α or β = s, l, g, and f denotes a pore fluid (i.e., l and g). For the mathematical convenience, it is assumed that every bulk phase is composed of the same set of electrically charged species, denoted by i = 1, 2, ..., Z, respectively. Let forumla be the mass concentration of species i in phase α, i.e., forumla, where forumla is the partial mass density of the i species in the α phase and ρα (forumla) is the intrinsic mass density of the bulk phase. With this notation, if a species is absent in a bulk phase, its concentration is zero, i.e., forumla. For convenience, all the other variables are summarized in the Appendix.

Formally, the following theoretical derivation follows the procedure adopted by Bennethum and Cushman (1996b) and Bennethum et al. (1996, 2000), with the assumption that the interfaces among bulk phases possess no thermodynamic properties. To avoid redundancy, only key assumptions and general results are given, and useful details of derivation can be found in the above-cited references. Nonetheless, for convenience of reference, the balance equations are summarized in the Appendix.

Constitutive Assumptions

The derivation starts with the assumptions regard to the specific Helmholtz free energy densities of three bulk phases, namely, As, Al, Ag, respectively. To this end, we introduce the principle of phase separation (Passman et al., 1984), stating that the Helmholtz free energy of a phase depends solely on its independent state variables. Based on this principle, As can be assumed as a function of temperature T, volume fraction ns, intrinsic mass density ρs, deformation gradient Fs and species mass concentration forumla (k = 1, 2, …, Z − 1), while Af as a function of T, nf, ρf, and forumla (k = 1, 2, …, Z − 1). Here it is noted that among all forumla, only Z − 1 components are independent. As argued by Passman et al. (1984), use of the phase separation principle is justified by the fact that individual bulk phases are physically separated in porous media.

In general, mass exchange may occur between the solid phase and the pore fluids. Thus, variables ns, ρs, and Fs are independent (recalling the solid mass balance, Eq. [A2] in the Appendix). Kinematically, the variation of soil porosity can be additively decomposed into two components: one is due to the skeletal deformation and/or the solid grain compression and the other solely due to the mass exchange (via, say, dissolution and precipitation). As a consequence, variation of ns also has two contributions, one of which can be solely attributed to the mass exchange (denoted as forumla). The evolution of forumla is governed by (see Appendix):
graphic
where forumla is the total mass exchange rate between the solid phase and pore fluid f.
Hence, it is proposed herein that
graphic

graphic

Inclusion of Lagrangian strain tensor Es instead of deformation gradient Fs in Eq. [2] is due to the requirement of objectivity. Clearly, all the arguments in As and Af are independent. From Eq. [2] and [3], it is noted that the solid matrix is assumed to be elastic and the pore fluids are of Newtonian-type. Viscous effect of pore fluids can be addressed by assuming a dependence of Af on ∇vf. For simplicity, however, ∇vf is excluded in Eq. [3].

Constraints by the Second Law

According to the second law of thermodynamics (see Appendix), it is necessary that
graphic

graphic

graphic

graphic
where ηα is the entropy density; τ s the intrinsic intergranular stress tensor, transited through grain–grain contacts; pα the thermodynamic pressure of α phase; 1 is the unit isotropic tensor with components of δij (i.e., Kronecker’s delta); forumla the electrochemical potential tensor of αi species; forumla the relative chemical potential of species forumla the diffusion velocity; νi the valence number of species i; forumla the molar mass of species i; and λ is a Lagrangian multiplier, associated with the electrical neutrality. Variables τ s, pα, and forumla are defined by
graphic

graphic

graphic
According to the Bowen (1982) definition, the total chemical potential tensor of a bulk phase is given by
graphic
It is straightforward to prove that
graphic
Here, the diffusion terms including forumla and forumla have been neglected, since these terms are generally small compared to the magnitude of forumla In addition, one has
graphic

graphic
Let forumla be the chemical potential tensor of a species. forumla can be related to forumla through
graphic
According to the classical definition of electrochemical potential (Atkins and dePaula, 2002), it is immediately apparent that multiplier λ is equal to forumla, where forumla is Faraday’s constant, and ξ is the local electric potential. Dropping all the diffusion terms, one can cast Eq. [7] into
graphic
The residual dissipation inequality is given by Eq. [A46] in the Appendix. To address chemical reactions in the porous media, consider several stoicheiometric chemical reactions (including dissolution–precipitation between the two bulk phases) occur in the pores, through which the solid matrix and the pore liquid (water) exchange mass. These chemical reactions can be generally represented by forumla, where [αi] represents the molar concentration [mol/m3] of species αi, and forumla represents the reaction coefficients of the Jth reaction ( J = 1, 2, ..., M). If a species (say αi) does not participate in the reaction, forumla; otherwise, forumla for a reactant, and forumla for a product. Let forumla be the rate of the Jth reaction, then
graphic

graphic
Substituting these two equation in Eq. [A46], one obtains the residual inequality as
graphic
where δsα = 1, if α = s; otherwise, δsα = 0;
graphic

graphic

forumla is the configurational pressure, which is sometimes called the swelling pressure for expansive soils (Bennethum and Weinstein, 2004; Bennethum, 2012); forumla represents the effort (with the same unit as pressure) required to break the chemical bonds of the solid material in the non-deformed condition.

Thermodynamic Equilibrium

Inequality [19] includes a set of independent variables {zm}with components ∇T, Dsn f/Dt, vf,s, forumla and forumla. It is straightforward to prove that the sufficient and necessary conditions for the porous media to attain equilibrium are
graphic

graphic

graphic

graphic

graphic

Equation [22] is the condition for thermal equilibrium, Eq. [23, 24, and 26] are the conditions for hydromechanical equilibrium, and Eq. [25] is the conditions for chemical equilibrium. Remarkably, for a system in equilibrium, all the thermal, hydromechanical, and chemical equilibrium conditions must be satisfied.

Several common results can be deduced from Eq. [25]. First, for a general chemical reaction occurring in pore fluids, δsf = 0, and Eq. [2.25] yields
graphic
Now consider a species j that can exchange its mass among the solid, the pore liquid, and the pore gas. Symbolically, this exchanging process can be represented as forumla. For exchange forumla, one can assume forumla, and it follows from Eq. [27] that
graphic
and for forumla (f = l or g), setting forumla, one obtains
graphic

An equation similar to Eq. [29] was derived by Bennethum et al. (1996, 2000), although the breaking energy term (i.e., forumla) appears here for the first time.

Let forumla be the electrochemical potential, and then forumla. Equation [28] states that the chemical potential of any species in a multiphasic system in equilibrium is continuous across the interfaces between bulk phases, which is consistent with the classical result of thermodynamics (Atkins and dePaula, 2002). Equation [29] is a new result, implying that the chemical equilibrium between the solid matrix and a pore fluid can be intervened by the intrinsic intergranular stress. In the left-hand side of Eq. [29], forumla accounts mainly for the elastic energy of the solid matrix, the second term is the elastic energy of the solid material, and the third term represents the energy required to break the chemical bonds of the solid material.

With Eq. [24], eliminating the exchange terms, forumla, from the linear momentum balance equations of pore fluids (Eq. [A6] in the Appendix), one can derive
graphic
where af is the acceleration of the fluid. Using the state equations for Gf, pf, , forumla and μf, Eq. [30] can be cast into
graphic
From Eq. [26], it follows that forumla (k = 1, 2, ..., Z − 1). Noting that af = 0 and ∇T = 0 at static equilibrium, one obtains
graphic
Integrating Eq. [32] yields
graphic
where i = 1, 2, ..., Z; sym( ) represents the symmetrical part of a second-order tensor; x and x0 are the spatial coordinates of the point of interest and the reference point, respectively; c is independent of spatial coordinate x. Clearly, at equilibrium, the sum of electrochemical and gravitational potentials is spatially uniform for any species.

Linear Dissipative Processes

In analyzing the behavior of a porous medium, it is crucial to characterize its evolution process. It is assumed herein that during its evolution process, the porous medium deviates only slightly from thermodynamic equilibrium. With this assumption, and according to Inequality [19], it is assumed that
graphic

graphic

graphic

graphic

graphic
where kq, θf, ξf, ζJ, and forumla (k = 1, 2, ..., Z − 1) are material coefficients. Here, for simplicity, all the cross effects have been neglected. Equation [34] is the generalized Fourier law for porous media with multiphase and multispecies; Eq. [35] describes the rate of the fluid volume fraction; Eq. [36] represents the constraint on the linear momentum exchange between bulk phases; Eq. [37] accounts for the mass exchange processes; Eq. [38] is the generalized Fick’s law for porous media with multiphase and multispecies.

It is remarkable that the second law does not exert any control on the linear momentum exchange of species, i.e., forumla. This result is different from the previous results (e.g., Bennethum and Cushman, 1996b; Bennethum et al., 1996, 2000). It is clear that within this context porous media are treated as highly reactive ones in the sense of Bataille and Kestin (1977).

Substituting Eq. [34–38] in Eq. [19] yields
graphic

Coefficient tensor kq, ξf, and forumla are symmetric and positively definite, and the scalar coefficients ςJ and θf are non-negative.

Chemical and Electrochemical Potentials

As discussed above, the chemical potential, forumla, (or electrochemical potential, forumla) of the species in the pore fluids plays a crucial role in characterizing the behavior of a porous medium with multiphase and multispecies. In the following, general expressions of forumla and forumla are developed for the pore fluids.

Decomposition of the Specific Helmholtz free energy of pore fluids

In Eq. [3], A f is assumed to be a function of T, ρf, and forumla (k = 1, 2, ..., Z − 1), as well as n f. The dependence of A f on n f accounts for the effect of the surface forces associated with interfaces, implying that a solution in the pores differs from that in the free bulk state in that the former is under the influence of the surface forces (Nitao and Bear, 1996). These surface forces include the surface tension on the interfaces and the adsorptive forces stemming from the physicochemical interactions among different bulk phases, including electrostatic forces, Van der Waals attraction, double-layer repulsion, and so on. In general, porous media (e.g., geomaterials) are electrically charged. Hence, it is expected that significant physicochemical interactions occur among mineral surfaces, water dipoles, and electrically charged species. These interactions can modify the potential energy of pore fluids, so that a fluid in the pores has a potential energy different from the fluid free of the surface forces at the same thermodynamic condition (temperature, mass density, and mass fractions).

To gain insight into the character of the specific Helmholtz free energy defined by Eq. [3], we adopted a procedure by Nitao and Bear (1996) to analyze the effect of surface forces on the energy potential. Consider a representative volume (REV) of a pore fluid at point x, at temperature T, average mass density ρf and mass fraction forumla. Consider also a reservoir forumla outside the porous medium domain containing the same fluid as the REV at the same thermodynamic conditions (T, ρf, and forumla). The reservoir is at the same reference elevation as the REV. It is important to note that, unlike the fluid in the reservoir, the pore fluid is subjected to the surface forces.

Now consider a system consisting of an infinitesimal amount of fluid in forumla. Let the system be transported, in a thermodynamically reversible manner, from forumla to the same sate as the REV. To maintain constant ρf and T during the movement, the same amount of surface forces as in the REV has to be applied to the system so that the system (the transported fluid) has the same potential field as in the REV. As a consequence, the system changes by a pressure Δp f and amount of specific heat Δq (= TΔηf). In applying the surface force, some amount of work must be externally input to the system. According to the principle of energy conservation, under the condition of constant T and ρf, the variation of specific internal energy, E f, of the system is given by ΔE f = −Δwf + TΔηf, or equivalently, E fforumla = −Δwf + Tfforumla ), where Δwf is the specific work done against the surface forces, and forumla and forumla are the specific internal energy and specific entropy of the system before applying the surface forces, that is, in forumla. Let Ωf be the surface energy potential, and Ωf = − Δwf < 0. Then, introducing the Legendre transformation (Eq. [A23] in the Appendix), one obtains
graphic
where A f and forumla are the specific Helmholtz free energies of the pore fluid in the REV and the fluid in forumla, respectively.

Remarkably, function forumla as defined is equal to the specific Helmholtz free energy of the system, i.e., the fluid in forumla. Hence, once forumla is defined, as a function of the same T, ρf , and forumla as in forumla, Ωf can be fully specified as a function of on T and nf only. Decomposition of energy potential has usually been exercised in addressing the effect of pore water films on the behavior of unsaturated porous media (e.g., Coussy, 2004, 2010). It is noted, however, that unlike the previous approaches (Coussy, 2004, 2010), here the surface energy potential Ωf is considered part of the free energy potential of the pore fluid, which is subjected to the surface forces.

A Generic Expression for Chemical Potential

To derive a generic formulation of chemical potential, consider a species in the pore fluid, denoted as fi. Consider a small representative volume, dV, of a deforming porous medium, whose initial volume before deformation is dV0. Apparently, dV can be related to dV0 through dV = JdV0, where J is the Jacobian of the deformation gradient, F, of the solid matrix, i.e., J = det(F) > 0. Hence, the total specific energy of the fluid with regard to dV0 is Jn fρfA f. Let forumla be the specific mass of a species fi with regard to dV0, i.e., forumla. According to its very definition, the chemical potential of species fi can be defined as (e.g., Bennethum and Cushman, 2002b)
graphic
Substituting Eq. [40] in Eq. [41], one obtains
graphic
where forumla is the chemical potential of a species in the bulk fluid free of surface forces, and
graphic
According to its classical definition (Atkins and dePaula, 2002), chemical potential forumla is explicitly given by
graphic
where forumla is the activity of the species that is a function of T, p f, and molar fraction ; forumla; R is the universal gas constant; forumla the chemical potential of the species fi at the pure state. Activity forumla is defined in such a way that it approaches forumla as forumla for a solute species, and forumla for the solvent. forumla is related to forumla through
graphic
Hence, the chemical potential can be expressed as
graphic
and the electrochemical potential is given by
graphic
To gain more insights into the composition and character of Ωf, recall the state equation for forumla, i.e., Eq. [20]. Using Eq. [40], one obtains
graphic
Integrating Eq. [47] yields
graphic
where forumla is the fluid volume fraction at full saturation, and for the wetting fluid, forumla is approximately equal to porosity n; forumla is considered as a function of T and n f. Equation [48] can be recast into
graphic
where
graphic

graphic
where 0+ is a small positive quantity, approaching zero. For the pore liquid, 0+ represents the smallest fluid volume fraction at which the porous medium is considered “dry.”

Assuming the dependence of A f on forumla is to highlight the fact that the surface energy potential depends on the porosity only through the fluid volume fraction, n f, which is equal to forumla multiplied by the degree of saturation, Sf. Noticeably, forumla in Eq. [48] can be viewed as the total surface energy potential of the pore fluid fully occupying the pore space in the porous medium, and forumla is equal to the work required to overcome both the adsorptive and capillary forces in transporting, in a thermodynamically reversible way, the fluid from a reservoir to fully saturate the porous medium at the same T, ρf, and forumla. Because the integral in Eq. [50] represents the surface energy potential associated with the capillary forces, it is clear from Eq. [50] that Af is indeed the surface energy potential accounting only for the adsorptive forces in a fully saturated porous medium.

As described by Eq. [49], the total surface energy potential has two contributions, i.e., Af and Cf. In the literature (e.g., Tuller et al., 1999), the surface energy (or matric) potential is usually decomposed into two components, which accounts for the effect of adsorptive forces and the effect of capillary forces, respectively. As implied by Eq. [49], it is generally difficult, if not impossible, to clearly distinguish Af and Cf, since both account for the effect of the adsorptive forces. Nevertheless, it is clear that only Cf depends on the degree of saturation (through n f) and accounts for the effects of both the adsorptive and capillary force, whereas Af is associated only with the effect of adsorptive forces in the porous media at full saturation.

Equilibrium Properties

Because forumla is a function of T, p f, n f, and forumla, enforcing equilibrium equations, Eq. [27–29] and Eq. [33] may yield rich colligative properties such as osmotic pressure, undercooling, superheating, and Kelvin effect in porous media. These properties describe the correlations among T, p f, n f, and forumla. Because of its central importance, the Donnan osmotic phenomenon is discussed in detail in the following, In addition, a detailed analysis of different procedures for measuring the negative pore water pressure in unsaturated soils is also given.

Donnan Osmotic Phenomenon

Consider a soil layer in the vadose zone, in which a groundwater observation well (denoted as W) is drilled down below the water table, as schematically shown in Fig. 1. The soil solution in the observation well keeps in contact, and in equilibrium, with the pore water in the soil. In the following, to distinguish the water solutions in the well and in the soil pores, they are called “equilibrium solution” and “pore water,” respectively. Suppose that the soil has a fixed charge density of cfix [mol/m3], which represents the total number of electric charges fixed in a unit volume of the soil. For the purpose of illustration, it is assumed that the fixed charges are negative and that both the soil solution and the pore water are composed of a solvent (H2O) and two charged species (X m− and Y n+), whose valence numbers are −m and n, respectively.

Consider Point A in the equilibrium solution in the well, which is at the same elevation as Point B in the soil. The condition of electrical neutrality requires that in the equilibrium solution,
graphic
where c0 [mol/m3] is the total number of negative charges in a unit volume of equilibrium solution. In the pore water,
graphic
At equilibrium, according to Eq. [33],
graphic
According to Eq. [46], the chemical potential of the solvents in the well and the soil are
graphic

graphic
where forumla is the mass density of pure water, which is assumed to be constant; forumla is the pressure of pure water at some reference state; forumla is the chemical potential of pure water.
For ions γ (= X m, Y n+), one has
graphic

graphic
where forumla and forumla are the mass density and chemical potential, respectively, of species γ at the pure state. Here, forumla is assumed to be constant. It is also noted that the local electric potential is zero in the well, where ions are uniformly distributed in the equilibrium solution.
Using Eq. [54], [57], and [58], it is straightforward to prove that
graphic
where forumla is the generalized osmotic pressure, and O(Π, Ωl) is given by
graphic
By substituting Eq. [55] and [56] in Eq. [54], one can derive
graphic
Comparing Eq. [60] and [61], one can see that O(Π, Ωl) is a small quantity, which is negligible in Eq. [59]. For a dilute solution, forumla , and forumla . Hence, one obtains
graphic

This equation can be solved for forumla and forumla , provided that c0, cfix, and n l are specified.

Remarkably, unless the soil has no fixed charges (i.e., cfix is zero), forumla is generally different than forumla. This phenomenon is usually called Donnan’s effect (Mitchell and Soga, 2005), which can be attributed to the existence of the fixed charges in the porous media. The example discussed here represents a special case, in which only two solutes (i.e., ions X m− and Y n+) exist in the water solution and the soil (at Point B) is fully saturated. In a more general case, where the water solution consists of multiple species, it can be expected that the mass concentrations of species are different in the pores than in the well; that is, forumla.

It follows from Eq. [61] that
graphic
where ΠD is the Donnan osmotic pressure, given by
graphic

Equation [63] is a general expression for the osmotic pressure in porous media, implying that Π has two contributions, namely, the Donnan osmotic pressure (ΠD) and the pressure induced by the surface forces forumla . Figure 2 depicts the dependence of ΠD on c0, cfix, and nl in a clayey soil saturated with a NaCl solution (i.e., i = H2O, Na+, Cl). It can be seen that ΠD could be significant, depending on c0, cfix, and nl.

Consider a point (denoted as C) in the vadose zone, whose vertical coordinate is xC (Fig. 1). At equilibrium, forumla , where forumla assumes a form similar to forumla , x0 is the vertical coordinate of the groundwater table, and b the gravitational acceleration. Now it is straightforward to prove that the true pore water pressure at point C is given by forumla . Because point C is arbitrarily chosen, one obtains a general expression for the true pore water pressure as
graphic
where forumla. In derivation, use is made of and forumla.

Clearly, pl differs from forumla by amount of Π. If a conventional transducer (say a tensiometer) is used to measure the “pore water pressure” in a soil, the measured value is indeed equal to forumla. In the following, forumla is called the “equilibrium solution pressure” to highlight the fact that forumla can be measured using a conventional transducer. Remarkably, both pl and forumla are mechanical pressures, and thus they can be used to describe the mechanical behavior of unsaturated soils. In constitutive modeling, however, it is critical to distinguish which pressure is used. Unfortunately, such an important issue traditionally has been overlooked.

Determination of Surface Energy Potential

For unsaturated soils, the effect of surface forces on A g is generally small, and the gaseous phase behaves as an ideal mixed gas. Hence, A g is assumed to be a function of T, p g, and C g only. According to Eq. [23], p g− p s = 0, and forumla = 0. It follows that
graphic
By substituting Eq. [65] in Eq. [66] and introducing Eq. [47] and [63], one derives
graphic
where forumla is the matric suction or the soil water characteristic function. For a dilute solution, forumla. By integrating Eq. [67] from nl to forumla, one obtains
graphic

Noticeably, while sM is a function of T and nl, ΠD can be considered as a function of T and nl only to the extent that both c0 and cfix are specified. In general, ΠD is a function of T, nl, and forumla, which has yet to be specified. Such a development goes beyond the scope of this paper and may become a topic for future research.

It is remarkable that Eq. [67] also applies to the fully saturated condition, at which
graphic

Here it is recalled that porosity n is equal to forumla. Equation [69] is the evolution equation for Ωl in fully saturated deforming soils. At infinitesimal deformation, the derivative term is negligible, so that forumla. Equation [63] yields Π(T, n) = sM(T, n). According to the very definition of the air entry value (AEV) of a soil, sM(T, n) simply equals to the AEV. Hence, at full saturation, the generalized osmotic pressure is equal to the air entry value of the soil.

Measurement of Negative Pore Water Pressure

In the following, three typical types of the techniques for measuring the negative equilibrium solution pressure (i.e.,forumla ) are introduced, including the tensiometer, the vapor equilibrium technique, and the axis-translation technique. Briefly discussed here are the working principles of these techniques, and for a detailed analysis of their advantages and limitations, interested readers can refer to related references (e.g., Ridley and Wray, 1996; Lu and Likos, 2004).

Tensiometer

A tensiometer consists of a ceramic filter with a high air entry value, a strain gauged diaphragm, and a small reservoir. The reservoir is located behind the ceramics and at the front of the strain gauged diaphragm. Before measurement, the ceramics and the reservoir have to be fully saturated. Then the tensiometer is inserted into the point of interest in the soil, at which the pore water contacts with the water in the reservoir of the tensiometer (i.e., the equilibrium solution) through the ceramics. Measurement begins after equilibrium is achieved.

The working principle of a tensiometer is quite similar to that of a traditional PWP. Unlike the traditional PWP transducer, however, a tensiometer includes a high air-entry value ceramics, which is used to prevent the air enters into the water reservoir in the tensiometer during the measurement. The pressure measured by a tensiometer is indeed forumla , as discussed above. The true pore water pressure can be recovered using Eq. [65]. Due to the water cavitation, a tensiometer can only be applied to measure a negative pore water pressure down to −100 kPa.

Axis-Translation Technique

To prohibit the water cavitation, the so-called axis-translation technique can be applied. Consider a representative volume of the unsaturated soil exposed to an ambient air pressure p g, at which the equilibrium solution pressure and the true pore water pressure are forumla and pl, respectively. To avoid the cavitation of pore water, pg is increased to forumla during the measurement. As a consequence, the true pore water pressure rises to forumla. Now consider a reservoir containing the soil solution in equilibrium with the pore water, and the solution pressure in the reservoir (denoted as forumla) remains constant during the measurement. For convenience, forumla can be chosen as the atmospheric pressure, patm.

According to Hilf (1956), if the saturation remains unchanged, the difference between the air pressure and pore water pressure is constant, i.e., forumla. Hence, one has
graphic
The applicability of the axis-translation technique depends mainly on the validity of Hilf’s assumption as stated above. Application of this technique has been seriously criticized by Baker and Frydman (2009). These authors argued that the pore water in a natural soil should cavitate when the pore water pressure drops down to the cavitation pressure (about −100 kPa), and artificially elevating the pore air pressure through the axis-translation technique could intervene in this natural cavitation process, rendering a pseudo behavior of the unsaturated soil. It is noted, however, that according to Eq. [65], the true pore water pressure (pl) is larger than forumla by amount of Π. If the cavitation occurs at pl = −100 kPa, then forumla = −(Π + 100) kPa. Hence, the range of forumla that ensures the validity of the axis-translation technique is given by
graphic

Based on the experimental data compiled in Baker and Frydman (2009), the cavitation tensions of many unsaturated soils, which is represented by the value forumla of at cavitation, are all significantly higher than 100 kPa. For example, the cavitation tension of Barcelona silt (Gens et al., 1995) is up to 1 to 2 MPa. Hence, it is suggested here that the axis-translation technique should be applicable when forumla is significantly lower than −100 kPa, and perhaps even in the whole range of matric suction in which this technique is commonly applied.

Vapor Equilibrium Technique

At low saturation, the aqueous phase in the pores is disconnected, and the water is adsorbed onto the grain surfaces, forming water films. To measure forumla , the vapor equilibrium technique can be applied, in which the relative humidity of the pore gas is controlled and monitored.

At equilibrium, the chemical potential of the solvent is continuous across the interface between the pore water and the pore gas, i.e., forumla . is given by Eq. [56], dropping subscript B, while
graphic
where forumla is the partial vapor pressure in the pore gas. If forumla takes the value of the saturated partial pressure of the vapor at T and pg, quantity forumla is indeed the relative humidity of the pore gas in the soil, which can be measured using either a psychrometer or filter papers (e.g., Lu and Likos, 2004). At the reference state, forumla. Hence, it follows that
graphic
To determine the equilibrium solution pressure (i.e., forumla ), one can substitute Eq. [65] into Eq. [73], and, after some rearrangements, obtain
graphic
where forumla is equal to the relative humidity, forumla , of the mixed gas in equilibrium with the equilibrium solution under the same T and pg as in the pores. Noticeably, determination of forumla requires the extraction of equilibrium solution from the soil.

Formulation of the Effective Stress Tensor

Intergranular and Effective Stresses

To model the constitutive behavior of unsaturated porous media, it is crucial to define the effective stress tensor properly. To explore this issue, recall the definition of the total stress tensor for a porous medium as a whole (e.g., Bowen, 1982); that is,
graphic
where all the diffusion velocity terms have been omitted.
In general, the effective stress can be defined only for the porous media at equilibrium. Combining state equations, Eq. [5] and [6], and equilibrium condition, Eq. [23], as well as Eq. [75], it is straightforward to prove that
graphic
where peq is the equivalent pore pressure, given by
graphic
As discussed in the previous sections, forumla . As a consequence, pg = ps and forumla. Hence, it follows from Eq. [76] that
graphic
where pl is given by Eq. [65]; that is, forumla. Substituting in Eq. [78], one can derive
graphic

Note that, for a dilute aqueous solution, forumla . Because ΠD is a function of T and nl to the extent that the mass fractions of species forumla (or, both c0 and cfix) are specified, peq is generally a function of pg, T, and nl, as well as forumla (k = 1, 2, ..., Z − 1).

Equation [79] can be cast into the form as peq = pg + σs, where σs is the so-called suction stress (Lu and Likos, 2006), and defined by
graphic
It follows from Eq. [76] that
graphic
where forumla is the intergranular stress tensor (e.g., Mitchell and Soga, 2005, see Chapter 7), which is the part of the total stress transferred through grain–grain contacts.
At full saturation, Π = ΠD − ρlΩl = sM = AEV and forumla , so that
graphic
where Π, ΠD, and Ωl are functions of T, n, and forumla , as discussed above. From the above derivations, it is clear that Eq. [81] can smoothly convert to Eq. [82] as the soil switches from a partially saturated state to full saturation.
In the classical soil mechanics textbook, Terzaghi’s effective stress tensor σ′ for the fully saturated soils is defined as forumla. Clearly, σ′ can be related to σI through
graphic

In the current practice of soil mechanics, Π is usually neglected, so that the effective stress and intergranular stress are used interchangeably. However, such a simplification is not always permissible, since the bracketed term or the generalized osmotic pressure in Eq. [83] may vary significantly when the physicochemical effect comes into play.

Evaluation of Pressure or Potential Functions

To apply the proposed theory, several pressure or potential variables have yet to be determined, including matric suction (or soil water characteristic function) sM, surface energy potential function Ωl, Donnan osmotic pressure ΠD and generalized osmotic pressure Π. In general, these variables are functions of temperature, pore water content (or saturation), and concentrations. Because of Eq. [63] and [68], only two of these variables are independent. Suction forumla can be routinely measured (see above sections), while Function forumla can be determined indirectly. One of the indirect methods for determining Π is to measure the shear strength of soils, incorporating the Mohr–Column criterion with Eq. [81] (e.g., Lu and Likos, 2006), from which ΠD and Ωl are determined with sM being given.

For some cases, one needs to measure sM only, and other variables can be calculated using Eq. [63], [64], and [68]. As an example, consider a drying process of a water-saturated clayey soil through vaporization, whose sM has been determined. Initially, the soil is fully saturated by a dilute NaCl solution, with a concentration corresponding to c0 = 100 mol/m3. The soil has a porosity of 0.6, and a fixed charged density of 30 mol/m3. Now the soil is slowly dried through vaporization (by reducing the humidity of the pore air) at room temperature (∼296 K) and atmospheric pressure, without any applied loads. As a first approximation, it is assumed that only the solvent (H2O) in the pore solution can vaporize, and other species (Na+ and Cl) remain in the pores. As such, one can calculate the variation of ΠD with saturation by following the procedure stated in the “Donnan Osmotic Phenomenon” section above. Variables Π and Ωl are then calculated using Eq. [63] and [68]. Because the initial state is at full saturation, forumla is conveniently chosen as zero.

The variations of Π, sM, ΠD, and Ωl with the liquid saturation are depicted in Fig. 3. It can be seen that both Π and ΠD increase with the decrease of saturation. In particular, as the saturation decreases, Ωl increases, implying that it becomes more and more difficult to remove the pore water, as is commonly observed in the laboratory. Figure 4 illustrates the variation of the mean intergranular stress, forumla , during the drying process. Clearly, as the degree of saturation decreases, the intergranular pressure (i.e., −pintGR) increases, and the soil becomes stronger and stronger. Noticeably, the variation of pintGR depends also on the fixed charge density and the initial concentration of pore water. As an illustration, the results of c0 = 10 and 500 mol/m3 are also given in Fig. 4 (other conditions remain unchanged). Unlike those at lower concentrations, for c0 = 500 mol/m3, the intergranular pressure first increases and then decreases. These results are consistent with those of the suction stress concept (Lu and Likos, 2006; Lu et al., 2010). Indeed, it has been well recognized that, during a drying process, some clayey soils may shrink first and become more and more aggregated at low saturation.

Theoretical Framework

In general, several coupled physical and chemical processes may occur in an unsaturated soil, including heat conduction, fluid flow, capillary relaxation, diffusion, phase transition and chemical reactions as well as irreversible deformation.

Heat Conduction Equation

Using energy balance equations (Eq. [A10–A18] in the Appendix) and Eq. [34], one can derive the heat conduction equation as
graphic
where forumla, and
graphic

TΛM is the rate of heat release associated with the physical and chemical processes occurring in porous media. Equation [84] takes the same form as derived by Coussy (2004). Noticeably, the dissipation associated with irreversible skeletal deformation is excluded in TΛM, since only the elastic deformation is considered here for clarity. Within this framework, however, the irreversible deformation can be incorporated in a straightforward way.

Pore Fluid Flow Equations

Using Eq. [36] to eliminating forumla from the linear momentum balance equation of a fluid (Eq. [A6] in the Appendix), one obtains
graphic
For the pore gas, forumla and thus
graphic
For the pore water, using Eq. [47] and acknowledging that Ωl is a function of T and nl, one can cast Eq. [86] into
graphic
Noting that for a dilute solution, forumla . Using Eq. [63] and [65], one obtains
graphic

Equation [88] and [89] are the general equations governing the pore fluid transport in the soils. Traditionally, the term ∇ΠD and ∇Ωl have been neglected, while forumla and pl are used indiscriminately. As implied by Eq. [88] and [89], however, such a practice must be exercised with caution.

In fully saturated porous media, ΠD depends on T and forumla (through c0 and cfix). Hence Eq. [89] implies that if forumla are heterogeneously distributed, there should exist a threshold of forumla , under which no filtration can occur. Indeed, in carefully prepared samples in which the fluid concentrations are uniformly distributed, such a threshold phenomenon does not occur (Mitchell and Soga, 2005).

Interestingly, Eq. [89] predicts the existence of a capillary fringe immediately above the groundwater table in the vadose zone (Fig. 1), where the soil is fully saturated and forumla is negative. To make this point transparent, consider the unsaturated soil at equilibrium under the atmospheric pressure and the isothermal condition, Eq. [89] becomes forumla . Assuming forumla and integrating this equation from x0 (the water table) to xLL, where xLL’ is the vertical coordinate of the plane separating the fully saturated and unsaturated zones (Fig. 1), one obtains the height of the capillary fringe as
graphic
where forumla is the equilibrium solution pressure at plane LL′ and forumla equals the AEV. As a consequence, forumla , that is, the true pore water pressure at xLL’ is zero.

The steady-state pressure profiles in the vadose zone deduced from Eq. [88] and [89] are illustrated in Fig. 1, which highlights the difference between pl and forumla. Remarkably, the forumla profile is different from the hydrostatic pressure profile, which is the case, since the gradients of T or forumla generally exist in the vadose zone.

Capillary Relaxation

For the gaseous phase, forumla. Using Eq. [35] and [47], one obtains
graphic
Assuming that Eq. [63] and [65] are valid in transient conditions, one can derive
graphic

Equation [90] and [91] is the evolution equation of nl that can be used to address the dynamic effect of capillarity (Hassanizadeh et al., 2002; O’Carroll et al., 2005; Manthey et al., 2008). It has been shown that the dynamic effect of capillarity can be attributed to local fluid flow in locally heterogeneous porous media (Wei and Muraleetharan, 2006, 2007).

Species Diffusion

Species diffusion occurs only in pore fluids. Multiplying Eq. [A2] by forumla , and then subtracting the resultant from Eq. [A1], it follows after some algebraic manipulations that
graphic
Substituting Eq. [17], [18], and [38] in Eq. [92], one obtains
graphic
where forumla can be determined once if the chemical reaction is specified.

Mass Exchange and Chemical Reactions

As discussed in earlier sections, the mass exchange processes among various bulk phases can be addressed through specifying several typical stoicheiometric chemical reactions. To derive a general equation governing the mass exchange and chemical reactions, we cast Eq. [37] into the Arrhenius’ type as
graphic
where forumla is the activation energy of reaction J; ΓJ is a coefficient accounting for the rate of reaction; forumla is the chemical affinity of the reaction, given by
graphic
where if forumla ; δsα = 1 if α = s, and otherwise δsα = 0.

In soils, the solid grains are generally coated by the aqueous phase (i.e., the pore water). Therefore, the reactions of main concern here may include vaporization–condensation between the pore water and pore gas, pressure solution–precipitation between the solid grains and the pore water, and the chemical reactions in pore fluids.

Vaporization–Condensation Process

For a vaporizing–condensing processes, it follows from Eq. [95] that
graphic
In a vaporizing process, forumla , whereas forumla in a condensing process. Using Eq. [56] and [72], it is straightforward to prove that
graphic
where forumla is the relative humidity of the pore gas, and forumla is the relative humidity of the equilibrium solution at T and pg (as in the pore gas). At equilibrium,
graphic
Here, subscript 0 denotes the equilibrium state. Linearizing Eq. [97] and using Eq. [98], one obtains
graphic

Pressure Solution–Precipitation

Pressure dissolution and precipitation occur only between the solid matrix and the pore water in unsaturated soils. Without loss of generality, consider a group of chemical reaction processes, which can be represented by
graphic

As an instance, the quartz dissolution is represented by forumla.

Accordingly, the chemical affinity is given by
graphic
where is a function of (or nr), defined by Eq. [21]; forumla and forumla represents the deviations of the chemical potentials from their equilibrium counterparts.
The chemical potential of a species in the solid phase is generally dominated by the volumetric strain energy of the solid skeleton. Thus, one can write
graphic
where pI (= −(τs : 1)/3) is the intergranular pressure. Noting that Δεv = ΔpI/K, where K is the secant bulk modulus of the solid matrix, Eq. [101] can be approximated as
graphic
where all the terms including forumla are dropped out, since they are generally much smaller than the bracketed term.

As implied by Eq. [103], a dissolving–precipitating process in the pores can be intervened by the intergranular pressure applied to the porous media. In general, however, the applied pressure and temperature do not exert simple controls on the pressure solution, since forumla is also involved in. For dissolution, forumla , whereas forumla for precipitation. In the early beginning of the dissolution, few chemical bonds break, and thus forumla. From Eq. [103], one can show that for the dissolution to occur, it requires that pI > K. Hence, there exists a threshold of the applied pressure, below which no pressure dissolution can occur. Clearly, as the pressure increases, more and more chemical bonds will break, i.e., forumla becomes more and more negative, and the dissolution will cease at forumla . These theoretical results are consistent with experimental observations (e.g., Taron and Elsworth, 2010).

Variable forumla is defined by Eq. [21]. Due to the current shortage of experimental data, it is impossible to develop here a realistic constitutive equation for forumla. As a first approximation, one can assume forumla based on the linearization of Eq. [21], where Θ is a positive material parameter. Provided that the mass exchange rates are given by Eq. [18], forumla can be determined by integrating Eq. [1].

Chemical Reactions in a Pore Fluid

The chemical affinity of a chemical reaction in a pore fluid is
graphic
Particularly, in the pore water, the chemical potential is given by
graphic
During a chemical reaction, both the mass and the number of electric charges are conserved. Hence, substituting Eq. [105] in Eq. [104], one obtains
graphic
where forumla is the molar volume of species li.

Noticeably, for a specified forumla , the first term in the right-hand side of Eq. [106] could be positive, zero, or negative, depending on the specific type of chemical reaction. Because forumla, one can conclude that pressurization and the surface forces in the pores could have different controls on the chemical reactions in porous media.

Summary and Conclusions

Developed here is a continuum theory of unsaturated soils, in which the soils are viewed as the porous media composed of multiphase and multispecies. Within the proposed framework, various coupling processes in unsaturated soils, including skeletal deformation, heat conduction, pore fluid flow, diffusion, phase transition, chemical reactions, and capillary relaxation, are addressed in a systematic and consistent way. The conditions for the thermal, mechanical, and chemical equilibrium of unsaturated soils are established, and the driving forces for various dissipative processes are identified and characterized. A general expression is developed for the chemical potential of a species in a fluid phase, which takes into account the thermal, pressure, osmotic, capillary, adsorptive, and electrostatic effects of unsaturated soils.

The behavior of unsaturated soils at equilibrium is investigated by enforcing the equilibrium conditions with incorporation of the proposed chemical potential formula. In particular, the Donnan osmotic phenomenon is discussed in detail, providing deep insights into the conception, composition, and measurement of pore water pressure, and a general formulation is developed for calculating the osmotic pressure. It is found that the true pore water pressure has three contributing components, including the equilibrium solution pressure, Donnan osmotic pressure, and the pressure induced by the surface forces. While the first component can be measured based on the conventional methods, the last two components cannot be directly measured. In addition, the experimental techniques used to measure the equilibrium solution pressure are discussed, and it is theoretically shown that the axis-translation technique can be applied, without water cavitation, down to a negative pressure much lower than expected.

Formulations of effective and intergranular stress tensors are developed for both fully saturated and unsaturated soils. It is suggested that it is the intergranular stress, instead of the effective stress, that controls the chemomechanical behaviors of both unsaturated and saturated soils. The new theory provides solid theoretical evidence for the recent development of the suction stress concept. In particular, a closed-form equation is developed for the suction stress, which can be used to describe the chemomechanical behavior of unsaturated soils.

A complete set of general governing equations are developed for addressing the chemomechanical behavior of unsaturated porous media in general, and unsaturated soils in particular, with a saturation ranging from extremely low to 100%. Remarkably, it is shown that other than the soil water characteristic function, another pressure (or potential) function Π(T ,nl ,forumla (or ΠD or Ωl) is generally required in analyzing the coupled chemomechanical processes in unsaturated soils. This conclusion is consistent with the recent development of the suction stress concept. The new theory is capable of explaining many salient phenomena occurring in water-saturated porous media, including Donnan osmosis, capillary fringe, air entry value, initial hydraulic head during seepage, pressure solution, and more.

This research was funded by one of National Basic Research Programs of China under Grant 2012CB026102, the National Science Foundation of China (NSFC) under Grants 51239010 and 11372078, and the Natural Science Foundation of Guangxi under Grant 2011 GXNSFE018004.

Appendix

Notation

Balance Equations and the Second Law

The balance equations and the second law of thermodynamics, originally developed by Hassanizadeh and Gray (1979a,b) and Gray and Hassanizadeh (1989) for multiphase porous media based on a local averaging procedure, and later generalized by Bennethum and Cushman (1996a; 2002a) to multispecies porous media, are introduced here. In the following derivations, no thermodynamic properties are assigned to the interfaces between bulk phases, and thus only the balance equations of species and bulk phases are introduced.

Mass Balance
The mass balance equation for a species is given by
graphic
Summing Eq. [A1] over i (= 1, 2, ..., Z) yields the mass balance equation for a bulk phase; that is,
graphic
where forumla , and vα is the velocity the mass center of the α phase, defined by
graphic
Mass conservation requires that
graphic
Linear Momentum Balance
The linear momentum balance equation for a species is given by
graphic
Summing up Eq. [A5] over i (= 1, 2, ..., Z) yields the linear momentum balance equation for a bulk phase; that is,
graphic
where tα, the Cauchy stress tensor of α phase, is given by
graphic
forumla is the diffusion velocity. Equation [A5] and [A6] are restricted by



graphic



graphic

Energy Balance
The energy balance equation for a species is given by
graphic
Summing up Eq. [A10] yields the energy balance equation for a bulk phase
graphic
where
graphic

graphic

graphic

graphic
Equation [A10] and [A11] are restricted by
graphic

graphic

graphic
The Second Law of Thermodynamics
The second law of thermodynamics requires that the rate of total entropy production Λ in the unsaturated soils due to dissipation be nonnegative; that is,
graphic
The entropy balance requires that
graphic

graphic

graphic
It has been well recognized that, in deriving a general thermomechanical theory of porous media, it is more convenient to use the Helmholtz free energy instead of the internal energy function. By Legendre transformation, the Helmholtz free energy density for a species and a bulk phase are defined, respectively, as
graphic
Using Eq. [A12] and noting that forumla , one can derive
graphic

Remarkably, Aα includes a contribution due to the diffusion of the species.

Replacing forumla in Eq [A19] by forumla and Aα, one can derive the following expression for the second law,
graphic

Additive Decomposition of Porosity

Introducing the mass balance equation of the solid phase (Eq. [A2]), one can derive
graphic
It is clear that the variation of porosity includes two contributions, which are induced by mechanical actions (including solid material compression and skeletal deformation) and mass exchanges, respectively. The variation of the porosity due to chemical reactions is described by
graphic
where the subscript “r” denotes the chemical reactions.

Constraints of the Second Law

Substituting Eq. [2] and [3] into Inequality [A25] can yield an expression of TΛ, which is a linear function of DαT/ DT, ∇vα, ∇T, vf,s, forumla , forumla , forumla and forumla (i = 1, 2, ..., Z). These variables are not independent, because ’s and ’s are correlated. Namely,
graphic
Taking the spatial gradient on both sides, one obtains
graphic
In addition, the species are electrically charged. The electrical neutrality requires that the total number of charges in the porous media be zero. According to this requirement, one has
graphic
where νi and forumla are the valence number and molar mass of charged species αi, respectively. νi < 0 (or > 0) for an anion (or a cation), and νi = 0 for a species with zero charge. Applying operator Ds/Dt to Eq. [A30], and introducing Eq. [A2], one can prove that
graphic
The constraints represented by Eq. [A28], [A29], and [A31] can be removed by using the Lagrange-multiplier method. To this end, the right-hand sides of Eq. [A28], [A29], and [A31] are first multiplied by multipliers forumla , forumla , and λ, respectively, and then added into the right-hand side of Eq. [A25]. Finally, introducing Eq. [2] and [3], one can derive
graphic
where λ is a scalar, forumla a vector, forumla a symmetric second-order tensor, and
graphic

graphic

graphic

graphic

graphic

graphic
In a general thermodynamic process, variables DαT/Dt, ∇vα, and forumla can vary arbitrarily. Hence, for Inequality [A32] to be constantly satisfied, it requires that
graphic

graphic

graphic

graphic

graphic
It follows from Eq. [A43] that
graphic
and from Eq. [A42] that
graphic
Using Eq. [A27] and Eq. [A39–A43], one obtains the residual dissipation inequality as
graphic
All rights reserved. No part of this periodical may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or any information storage and retrieval system, without permission in writing from the publisher.
Open access
